Exide AGM12-10.5 · Motorcycle battery 12V 10Ah 160A AGM
Specifications
| Brand | EXIDE |
|---|---|
| Part number | AGM12-10.5 |
| Capacity (C20) | 10Ah (c20) |
| Technology | AGM |
| Length | 150mm |
| Width | 70mm |
| Height | 130mm |
| Weight | 3.60 Kg |
| Terminal layout | Positive left |
This product is priced on demand to offer you the best available price at all times.
Please contact us to request a quote and we will inform you about availability and the best price on the entire website, as well as the delivery time.
Thank you
Exide AGM12-10.5 10Ah 160A is a sealed motorcycle battery ready to fit, with the JIS reference your mechanic recognises at a glance. Vibration-resistant, keeps voltage during the winter off-season and cranks first time when you take it out for a ride.
Why this motorcycle battery?
- Same JIS referenceas your bike's original — fits first time
- Sealed and ready to useno acid handling, no refills
- Survives winter storageholds charge through long off-season
Capacity
10 Ah
Cold cranking
160 A
Dimensions
150×70×130 mm
Technology
AGM
Polarity
Positive on the left
Weight
3,6 kg
Free quote, no obligation
Request a quote for your Motorcycle battery Exide AGM12-10.5 12V 10Ah 160A AGM
- Reply in under 24 working hours
- Best price guaranteed
Motorcycle battery Exide AGM12-10.5 10Ah 160A 12V
12VVoltage
10AhCapacity
160ACold cranking
3.60kgWeight
With 10 Ah at 12 V and 160 A of cold cranking current (EN), the Exide AGM12-10.5 with AGM technology replaces the original battery of motorcycles, scooters, quads and personal watercraft. Its 150 × 70 × 130 mm and the positive terminal on the left make it the exact replacement for the 10 Ah battery fitted as standard to many motorcycles.
- Sealed and ready to fit, no acid handling.
- AGM: faster recharging and better cycle resistance than a conventional battery.
- Compact and lightweight format.
- Holds its charge through winter storage.
Size, terminals and hold-down of the Exide AGM12-10.5
It has external dimensions of 150 × 70 × 130 mm and weighs 3.60 kg. The positive terminal on the left decides which side the cables end up on: it is the detail that causes most buying mistakes, so check it before ordering. It uses a B00 hold-down and M04 terminals, the system that anchors and connects it in the vehicle. For a direct replacement, the current battery tray must accept these dimensions and the same terminal layout; otherwise adapters will be needed or the hold-down will change.
What the Exide AGM12-10.5 is for
Designed for motorcycles, scooters, quads and personal watercraft, the Exide AGM12-10.5 replaces the original battery of bikes that use this code or format. Check the position of the positive terminal before ordering. Check that it matches your current battery in dimensions, terminals and hold-down: this reference has a weight of 3.60 kg, M04 terminals and B00 hold-down.
Technology inside the Exide AGM12-10.5
The AGM12-10.5 is one of the Exide references for this type of use; it shares the same manufacturing and quality-control criteria as the rest of the brand's catalogue.
In an AGM battery the electrolyte is absorbed in glass-fibre separators: there is no free liquid, it cannot spill and it can be mounted at an angle. That construction lowers internal resistance, speeds up recharging and multiplies cycle life compared with a conventional battery.
Exide: the maker behind the AGM12-10.5
Exide is one of the world's largest battery manufacturers and an original-equipment supplier to many car makers. Its European plants produce starter, industrial and leisure batteries under original-equipment quality controls. All the Exide batteries in our catalogue are genuine product, recently manufactured and covered by the manufacturer's warranty.
Manufacturer's warranty
The Exide AGM12-10.5 comes with the manufacturer's official warranty. The warranty does not cover discharge through prolonged inactivity: if the bike stands for months, use a trickle charger.
How to make it last longer
Check the resting voltage before the season (above 12.6 V on a charged battery) and make sure the terminals are clean and tight. Charge with a charger that has an AGM mode: it limits the voltage and protects the glass-fibre separators.
Delivery times and returns
Orders placed before 6:00 pm with the battery in stock ship the same day. Delivery in mainland Spain and Portugal takes 24-48 working hours; for the Balearic and Canary Islands and the rest of the European Union allow 3 to 5 working days. You have 14 days to return an unused battery; in mainland Spain and Portugal collection is free. We email you the tracking number as soon as the parcel ships.
BCOM-EXIDE-AGM12-10.5
Data sheet
- Length
- 150mm
- Width
- 70mm
- Height
- 130mm
- Weight
- 3.60 Kg
- Technology
- AGM
- EAN
- 3661024038119
- Terminal layout
- Positive left
- Terminal type
- M04
- Hold-down
- B00
- Cold cranking amps (EN)
- 160A
- Capacity (C20)
- 10Ah (c20)
Specific References
- EAN13
- 3661024038119
- MPN
- AGM12-10.5
Codes and references Exide AGM12-10.5
| Brand | Exide · see all batteries Exide |
|---|---|
| Manufacturer reference (MPN) | AGM12-10.5 |
| EAN-13 barcode | 3661024038119 |
| Dimensions (length × width × height) | 150 × 70 × 130 mm (150x70x130) |
Comparison: Exide AGM12-10.5 vs equivalents
The Exide AGM12-10.5 is interchangeable with these equivalent references: ET12B-BS (Exide).
| Product | Specifications | Technology | Price |
|---|---|---|---|
Exide
AGM12-10.5
This battery
|
|||
Exide
ET12B-BS
|
12V 10Ah 160A | AGM | €36.20 |
Equivalences verified by our technical team: same dimensions, polarity, capacity and CCA. Official manufacturer warranty on every option.
How to change the battery
Guide to replace your motorcycle battery in 10-15 minutes. Motorcycle batteries are light (2-5 kg) and usually need an 8 mm wrench.
Step 1. Prepare the vehicle
Park on a flat surface, switch off the engine and remove the key. Make sure all lights and electrical accessories are off. Wait 1-2 minutes before starting.
Step 2. Locate the battery compartment
On motorcycles it is usually under the seat, in the rear cowl or behind a side panel. Check the manual — access varies a lot between models.
Step 3. Disconnect the negative (−) terminal
Use the 10 mm wrench to loosen the negative cable nut (black, marked −) and remove the cable from the post. Move it aside so it cannot touch any bodywork.
Step 4. Disconnect the positive (+) terminal
Repeat with the positive cable (red, marked +). Important: never let a terminal touch metal of the car while the other is still connected.
Step 5. Remove the old battery
Loosen the hold-down clamp or the straps that secure it. Lift the battery carefully — typical weight 2-5 kg. Check the terminals are not corroded before fitting the new one.
Step 6. Install the new battery
Place the battery in the same orientation as the old one (positive terminal on the same side). Tighten the hold-down clamp firmly.
Step 7. Connect the cables
Connect the positive (+) terminal first, then the negative (−). Tighten the nuts with the wrench until each terminal does not move. Apply anti-spark grease if you have any.
Step 8. Verify the engine starts
Close the bonnet. Start the engine to confirm everything works. On cars with Start-Stop or a BMS, you may need to register the battery via OBD so the alternator applies the correct charging profile.
Frequently asked questions
How do I fit the AGM12-10.5 model in my motorcycle?
In most motorcycles it fits in 15-30 minutes with a 10 mm wrench; if the battery is under the seat or in the boot the time can double. See the step-by-step guide on this page. Quick summary: 1) switch off the engine and remove the key; 2) locate the original battery (engine bay, boot or under seat); 3) disconnect the negative (−) terminal first, then the positive (+); 4) loosen the hold-down clamp and remove the old battery; 5) fit the new one in the same orientation — match the polarity shown on the product sheet; 6) connect the positive (+) first, then the negative (−). On motorcycles with Start-Stop or BMS, register the battery via OBD so the alternator applies the correct charging profile.
How long does the Exide AGM12-10.5 battery last?
Expected lifespan of the Exide AGM12-10.5 is 4 to 7 years in regular use (depends on technology and climate). In cold regions it drops slightly due to cold-start stress; in very hot regions it also drops because of electrolyte evaporation. To extend its life: avoid deep discharges (headlights on with engine off), have the alternator checked yearly, and keep the battery clean and properly secured.
What are the measurements of the AGM12-10.5 model?
Dimensions (length × width × height) are 150×70×130 mm — also written as 150x70x130 mm — following the European DIN standard. Always measure the space in your motorcycle before buying: even one extra millimetre can prevent the hold-down clamp from closing. The height shown includes the terminals.
Is the AGM12-10.5 valid for my vehicle?
Three options to confirm: 1) enter your number plate in the finder (DGT/DVLA/KBA auto-detect your model and engine); 2) check the "Compatible vehicles" tab on this page, where we list every vehicle verified by our technical team; 3) if you cannot find your model, message us on WhatsApp with brand, model, engine and year — we reply during business hours (Mon–Fri 10:00–13:30 and 16:40–18:00 (Spanish time, CET)). The AGM12-10.5 typically fits a wide range of European vehicles thanks to its standard DIN case format.
What are the equivalents of the AGM12-10.5 model?
Directly interchangeable batteries (same dimensions, same polarity, same Ah and CCA) are the OEM equivalents from leading brands: Bosch, Tudor, Exide and, depending on the model, Banner or Yuasa. Exact equivalence depends on technology — an EFB cannot be replaced with a conventional battery in Start-Stop motorcycles. See the "Equivalents" section to view recommended options at the same performance level.
