Ritar RA12-240A · Caravan battery 12V 254Ah AGM
Specifications
| Brand | RITAR |
|---|---|
| Part number | RA12-240A |
| Voltage (V) | 12 |
| Capacity (C20) | 254Ah (c20) |
| Capacity (C10) | 240Ah (c10) |
| Technology | AGM |
| Length | 522.00 mm |
| Width | 240.00 mm |
| Height | 224.00 mm |
€686.40
VAT included
4,80/5★★★★★10 reviewsVerified purchases
- ★★★★★Vicente Cabrera:
Me ayudaron a elegir la batería más adecuada
- ★★★★Pablo Gutierrez:
Necesitaba con urgencia una batería de coche y me llegó al día siguiente de pedirla
- ★★★★★Marc Garrido:
Al final fue facil la instalación gracias a su ayuda
Ritar RA12-240A 12V 254Ah is a leisure battery for campers, motorhomes and caravans. Designed to power the entire interior kit (fridge, heater, water pump, USB, LED lighting) for several days off-grid, with no need to plug into a campsite hookup.
Why this caravan battery?
- Real off-grid autonomyno campsite hookup needed
- Lasts the whole seasonhandles daily discharges without capacity loss
- Powers it all at oncefridge, water pump, LED and USB without issues
Voltage
12 V
Capacity
254 Ah
Dimensions
522×240×224 mm
Technology
AGM
Weight
43,7 kg
Model
RITAR RA
Leisure battery Ritar RA12-240A RA 254Ah 240A 12V
12VVoltage
254AhCapacity
240ACold cranking
43.70kgWeight
The Ritar RA12-240A with AGM technology stores 254 Ah at 12 V: autonomy for motorhomes, caravans and campers that need power off-grid. It replaces the original battery without adaptation in motorhomes and caravans with a 522 × 240 × 224 mm format: same 254 Ah capacity.
- AGM technology: absorbed electrolyte, no spills, can be mounted at an angle.
- Power for fridge, lighting, water pump and USB off-grid.
- Sealed and gas-free: suitable for installation inside the living area.
- Low self-discharge during months of storage.
Dimensions, polarity and mounting
In terms of format, the Ritar RA12-240A measures 522 × 240 × 224 mm (length × width × height) and weighs 43.70 kg. It uses M8 terminals, the system that anchors and connects it in the vehicle. Checking the three dimensions and the terminal position before buying avoids the most common mistake when replacing a battery.
What the Ritar RA12-240A is for
As a leisure battery, the Ritar RA12-240A is discharged and recharged every travelling day; avoid discharges below 50% to extend its life. Check that it matches your current battery in dimensions, terminals and hold-down: this reference has a weight of 43.70 kg and M8 terminals.
The Ritar RA12-240A: RA range and AGM technology
The RA12-240A is part of the Ritar RA range. Choosing the right reference within the series comes down to capacity, dimensions and terminals: technology and quality are common to the whole family.
AGM (Absorbent Glass Mat) technology seals the electrolyte in glass microfibre. The result is a maintenance-free battery that is highly vibration-resistant and able to withstand deep discharges that would ruin a classic lead-acid battery.
What Ritar does differently
Ritar is one of the world's largest VRLA battery manufacturers. Its RA, RT, RL, HR and FT series equip UPS, telecoms and solar systems worldwide with very consistent quality. All the Ritar batteries in our catalogue are genuine product, recently manufactured and covered by the manufacturer's warranty.
Manufacturer's warranty
The Ritar RA12-240A comes with the manufacturer's official warranty against manufacturing defects. Avoid repeated full discharges: they shorten its life and are not covered.
Care and maintenance
During months of storage, keep it charged with a mains charger or a small solar panel; a battery left discharged for weeks loses capacity permanently. Avoid routinely discharging the leisure battery below 50% and recharge it fully after every trip.
Shipping, delivery and returns
Same-day dispatch from our warehouse for in-stock orders placed before 6:00 pm: 24-48 working hours in mainland Spain and Portugal, 3 to 5 days in the islands and the rest of Europe. Returns are accepted for 14 days if the battery has not been used (free collection on the Iberian mainland). You will receive tracking by email.
BCOM-RITAR-RA12-240A
Data sheet
- Brand
- RITAR
- Reference
- RA12-240A
- Model
- RITAR RA
- Voltage (V)
- 12
- Length
- 522.00 mm
- Width
- 240.00 mm
- Height
- 224.00 mm
- Technology
- AGM
- Terminal type
- M8
- Capacity (C20)
- 254Ah (c20)
- Capacity (C10)
- 240Ah (c10)
Specific References
- MPN
- RA12-240A
4,80/5
Verified purchasesLatest verified reviews
★★★★★Vicente Cabrera
18/05/2026Su ayuda fue valiosa
Me ayudaron a elegir la batería más adecuada
★★★★★Pablo Gutierrez
31/01/2026Excelente tienda de baterías de coches
Necesitaba con urgencia una batería de coche y me llegó al día siguiente de pedirla
★★★★★Marc Garrido
29/12/2025Se preocupan por asesorarte de la mejor manera
Al final fue facil la instalación gracias a su ayuda
★★★★★Julio Carmona
27/10/2025Gracias por su asesoramiento
Me ayudaron a elegir la bateria más adecuada
Recommended accessories
How to change the battery
Guide to replace the leisure battery of your motorhome or caravan. Estimated time 15-25 minutes. Important: isolate the 12V auxiliary system before handling.
Step 1. Switch off 12V equipment and unplug shore power
Turn off fridge, lights, water pump, Truma Mover and other auxiliary loads. Disconnect the 230V shore power and solar panels if any.
Step 2. Locate the leisure battery compartment
On motorhomes usually under the driver/passenger seat, in an outside locker or in the garage area. Verify this is NOT the engine starter battery — that one is up front with the engine.
Step 3. Disconnect the negative (−) terminal
Use the 10 mm wrench to loosen the negative cable nut (black, marked −) and remove the cable from the post. Move it aside so it cannot touch any bodywork.
Step 4. Disconnect the positive (+) terminal
Repeat with the positive cable (red, marked +). Important: never let a terminal touch metal of the car while the other is still connected.
Step 5. Remove the old battery
Loosen the bottom hold-down clamp with the same wrench. Lift the battery carefully (it can weigh 15-25 kg). Clean the tray with a brush and baking soda if there is corrosion.
Step 6. Install the new battery
Place the battery in the same orientation as the old one (positive terminal on the same side). Tighten the hold-down clamp firmly.
Step 7. Connect the cables
Connect the positive (+) terminal first, then the negative (−). Tighten the nuts with the wrench until each terminal does not move. Apply anti-spark grease if you have any.
Step 8. Verify the charger and auxiliary services
After connecting, check the combi charger (CBE/Schaudt/Nordelettronica) recognises the new battery: voltage should stabilise at 13.2-13.8 V with 230V connected. Test a couple of services (lights + pump) before heading out.
Frequently asked questions
Is the RA12-240A model AGM? What does this technology offer?
Yes. The RA12-240A from Ritar uses AGM (Absorbent Glass Mat) technology: a sealed lead-acid battery where the electrolyte is absorbed in a glass-fibre mat. It withstands more charge/discharge cycles than a conventional one, handles heat better and is the required technology for caravans with advanced Start-Stop and regenerative braking. Expected lifespan: 5-8 years under normal conditions.
How is the Ritar RA12-240A battery installed in the vehicle?
In most caravans it fits in 15-30 minutes with a 10 mm wrench; if the battery is under the seat or in the boot the time can double. See the step-by-step guide on this page. Quick summary: 1) switch off the engine and remove the key; 2) locate the original battery (engine bay, boot or under seat); 3) disconnect the negative (−) terminal first, then the positive (+); 4) loosen the hold-down clamp and remove the old battery; 5) fit the new one in the same orientation — match the polarity shown on the product sheet; 6) connect the positive (+) first, then the negative (−). On caravans with Start-Stop or BMS, register the battery via OBD so the alternator applies the correct charging profile.
What is the service life of the RA12-240A model?
Expected lifespan of the Ritar RA12-240A is 5 to 8 years in mild-climate caravan use with Start-Stop. In cold regions it drops slightly due to cold-start stress; in very hot regions it also drops because of electrolyte evaporation. To extend its life: avoid deep discharges (headlights on with engine off), have the alternator checked yearly, and keep the battery clean and properly secured.
What are the dimensions of the Ritar RA12-240A battery?
Dimensions (length × width × height) are 522×240×224 mm — also written as 522x240x224 mm — following the European DIN standard. Always measure the space in your caravan before buying: even one extra millimetre can prevent the hold-down clamp from closing. The height shown includes the terminals.
Will the Ritar RA12-240A battery fit my caravan?
Three options to confirm: 1) enter your number plate in the finder (DGT/DVLA/KBA auto-detect your model and engine); 2) check the "Compatible vehicles" tab on this page, where we list every vehicle verified by our technical team; 3) if you cannot find your model, message us on WhatsApp with brand, model, engine and year — we reply during business hours (Mon–Fri 10:00–13:30 and 16:40–18:00 (Spanish time, CET)). The RA12-240A typically fits a wide range of European vehicles thanks to its standard DIN case format.
What are the equivalents of the RA12-240A model?
Directly interchangeable batteries (same dimensions, same polarity, same Ah and CCA) are the OEM equivalents from leading brands: Bosch, Tudor, Exide and, depending on the model, Banner or Yuasa. Exact equivalence depends on technology — an EFB cannot be replaced with a conventional battery in Start-Stop caravans. See the "Equivalents" section to view recommended options at the same performance level.
