Ritar RA6-200 · Caravan battery 6V 212Ah AGM
Specifications
| Brand | RITAR |
|---|---|
| Part number | RA6-200 |
| Voltage (V) | 6 |
| Capacity (C20) | 212Ah (c20) |
| Capacity (C10) | 200Ah (c10) |
| Technology | AGM |
| Length | 322.00 mm |
| Width | 177.50 mm |
| Height | 247.00 mm |
€304.50
VAT included
4,83/5★★★★★10 reviewsVerified purchases
- ★★★★★Mateo Aguilar:
No sabía qué bateria llevaba mi coche y me ayudaron a seleccionarla
- ★★★★★Sebastian Diez:
No sabía qué batería llevaba mi coche y me ayudaron a seleccionarla
- ★★★★Rodrigo Carrasco:
Necesitaba con urgencia una batería de coche y me llegó al día siguiente de pedirla
Ritar RA6-200 6V 212Ah is a leisure battery for campers, motorhomes and caravans. Designed to power the entire interior kit (fridge, heater, water pump, USB, LED lighting) for several days off-grid, with no need to plug into a campsite hookup.
Why this caravan battery?
- Real off-grid autonomyno campsite hookup needed
- Lasts the whole seasonhandles daily discharges without capacity loss
- Powers it all at oncefridge, water pump, LED and USB without issues
Voltage
6 V
Capacity
212 Ah
Dimensions
322×177×247 mm
Technology
AGM
Weight
27,5 kg
Model
RITAR RA
Leisure battery Ritar RA6-200 RA 212Ah 6V
6VVoltage
212AhCapacity
27.50kgWeight
The 6 V, 212 Ah Ritar RA6-200 battery from the RA range with AGM technology is designed for motorhomes, caravans and campers that need power off-grid. It replaces the original battery without adaptation in motorhomes and caravans with a 322 × 177 × 247 mm format: same 212 Ah capacity.
- AGM technology: absorbed electrolyte, no spills, can be mounted at an angle.
- Power for fridge, lighting, water pump and USB off-grid.
- Sealed and gas-free: suitable for installation inside the living area.
- Low self-discharge during months of storage.
What the Ritar RA6-200 is for
With 212 Ah, the Ritar RA6-200 is the habitation battery for motorhomes, caravans and campers that need power off-grid. It recharges from the alternator, a solar panel or a mains charger. Check that it matches your current battery in dimensions, terminals and hold-down: this reference has a weight of 27.50 kg and M8 terminals.
The Ritar RA6-200: RA range and AGM technology
The RA is the Ritar range the RA6-200 belongs to: it shares the same construction and quality criteria with the rest of the series, and varies in capacity and format to suit each vehicle.
In an AGM battery the electrolyte is absorbed in glass-fibre separators: there is no free liquid, it cannot spill and it can be mounted at an angle. That construction lowers internal resistance, speeds up recharging and multiplies cycle life compared with a conventional battery.
Will it fit your current battery tray?
It has external dimensions of 322 × 177 × 247 mm and weighs 27.50 kg. It uses M8 terminals, the system that anchors and connects it in the vehicle. Checking the three dimensions and the terminal position before buying avoids the most common mistake when replacing a battery.
Why choose Ritar batteries
With more than twenty years making sealed lead batteries, Ritar offers general-purpose, long-life, high-rate and front-terminal ranges for every stationary application. All the Ritar batteries in our catalogue are genuine product, recently manufactured and covered by the manufacturer's warranty.
How to make it last longer
During months of storage, keep it charged with a mains charger or a small solar panel; a battery left discharged for weeks loses capacity permanently. Charge with a charger that has an AGM mode: it limits the voltage and protects the glass-fibre separators.
Official warranty
The Ritar RA6-200 comes with the manufacturer's official warranty against manufacturing defects. Avoid repeated full discharges: they shorten its life and are not covered.
When you get it and how to return it
Same-day dispatch from our warehouse for in-stock orders placed before 6:00 pm: 24-48 working hours in mainland Spain and Portugal, 3 to 5 days in the islands and the rest of Europe. Returns are accepted for 14 days if the battery has not been used (free collection on the Iberian mainland). You will receive tracking by email.
BCOM-RITAR-RA6-200
Data sheet
- Brand
- RITAR
- Reference
- RA6-200
- Model
- RITAR RA
- Voltage (V)
- 6
- Length
- 322.00 mm
- Width
- 177.50 mm
- Height
- 247.00 mm
- Technology
- AGM
- Terminal type
- M8
- Capacity (C20)
- 212Ah (c20)
- Capacity (C10)
- 200Ah (c10)
Specific References
- MPN
- RA6-200
4,83/5
Verified purchasesLatest verified reviews
★★★★★Mateo Aguilar
21/09/2026Gracias por la ayuda
No sabía qué bateria llevaba mi coche y me ayudaron a seleccionarla
★★★★★Sebastian Diez
12/07/2026Buen asesoramiento
No sabía qué batería llevaba mi coche y me ayudaron a seleccionarla
★★★★★Rodrigo Carrasco
06/02/2026Buen precio, calidad y envío
Necesitaba con urgencia una batería de coche y me llegó al día siguiente de pedirla
★★★★★Sebastian Gallego
04/02/2026Buenos profesionales, gracias por su ayuda
Esta web es la mejor, encontré lo que buscaba, llegó en menos de 24hrs y cuando llamé por una duda que tenía me ayudaron con la instalación
Recommended accessories
How to change the battery
Guide to replace the leisure battery of your motorhome or caravan. Estimated time 15-25 minutes. Important: isolate the 12V auxiliary system before handling.
Step 1. Switch off 12V equipment and unplug shore power
Turn off fridge, lights, water pump, Truma Mover and other auxiliary loads. Disconnect the 230V shore power and solar panels if any.
Step 2. Locate the leisure battery compartment
On motorhomes usually under the driver/passenger seat, in an outside locker or in the garage area. Verify this is NOT the engine starter battery — that one is up front with the engine.
Step 3. Disconnect the negative (−) terminal
Use the 10 mm wrench to loosen the negative cable nut (black, marked −) and remove the cable from the post. Move it aside so it cannot touch any bodywork.
Step 4. Disconnect the positive (+) terminal
Repeat with the positive cable (red, marked +). Important: never let a terminal touch metal of the car while the other is still connected.
Step 5. Remove the old battery
Loosen the bottom hold-down clamp with the same wrench. Lift the battery carefully (it can weigh 15-25 kg). Clean the tray with a brush and baking soda if there is corrosion.
Step 6. Install the new battery
Place the battery in the same orientation as the old one (positive terminal on the same side). Tighten the hold-down clamp firmly.
Step 7. Connect the cables
Connect the positive (+) terminal first, then the negative (−). Tighten the nuts with the wrench until each terminal does not move. Apply anti-spark grease if you have any.
Step 8. Verify the charger and auxiliary services
After connecting, check the combi charger (CBE/Schaudt/Nordelettronica) recognises the new battery: voltage should stabilise at 13.2-13.8 V with 230V connected. Test a couple of services (lights + pump) before heading out.
Frequently asked questions
Is the Ritar RA6-200 an AGM battery and what are the benefits of AGM?
Yes. The RA6-200 from Ritar uses AGM (Absorbent Glass Mat) technology: a sealed lead-acid battery where the electrolyte is absorbed in a glass-fibre mat. It withstands more charge/discharge cycles than a conventional one, handles heat better and is the required technology for caravans with advanced Start-Stop and regenerative braking. Expected lifespan: 5-8 years under normal conditions.
How is the Ritar RA6-200 battery installed in the vehicle?
In most caravans it fits in 15-30 minutes with a 10 mm wrench; if the battery is under the seat or in the boot the time can double. See the step-by-step guide on this page. Quick summary: 1) switch off the engine and remove the key; 2) locate the original battery (engine bay, boot or under seat); 3) disconnect the negative (−) terminal first, then the positive (+); 4) loosen the hold-down clamp and remove the old battery; 5) fit the new one in the same orientation — match the polarity shown on the product sheet; 6) connect the positive (+) first, then the negative (−). On caravans with Start-Stop or BMS, register the battery via OBD so the alternator applies the correct charging profile.
How long does the Ritar RA6-200 battery last?
Expected lifespan of the Ritar RA6-200 is 5 to 8 years in mild-climate caravan use with Start-Stop. In cold regions it drops slightly due to cold-start stress; in very hot regions it also drops because of electrolyte evaporation. To extend its life: avoid deep discharges (headlights on with engine off), have the alternator checked yearly, and keep the battery clean and properly secured.
What size is this battery?
Dimensions (length × width × height) are 322×178×247 mm — also written as 322x178x247 mm — following the European DIN standard. Always measure the space in your caravan before buying: even one extra millimetre can prevent the hold-down clamp from closing. The height shown includes the terminals.
Does this battery fit my caravan?
Three options to confirm: 1) enter your number plate in the finder (DGT/DVLA/KBA auto-detect your model and engine); 2) check the "Compatible vehicles" tab on this page, where we list every vehicle verified by our technical team; 3) if you cannot find your model, message us on WhatsApp with brand, model, engine and year — we reply during business hours (Mon–Fri 10:00–13:30 and 16:40–18:00 (Spanish time, CET)). The RA6-200 typically fits a wide range of European vehicles thanks to its standard DIN case format.
What are the equivalents of the RA6-200 model?
Directly interchangeable batteries (same dimensions, same polarity, same Ah and CCA) are the OEM equivalents from leading brands: Bosch, Tudor, Exide and, depending on the model, Banner or Yuasa. Exact equivalence depends on technology — an EFB cannot be replaced with a conventional battery in Start-Stop caravans. See the "Equivalents" section to view recommended options at the same performance level.
