Tudor TB110B · Car battery 12V 110Ah 950A
Specifications
| Brand | TUDOR |
|---|---|
| Part number | TB110B |
| Voltage (V) | 12 |
| Capacity (C20) | 110Ah (c20) |
| Cold cranking amps (EN) | 950A |
| Technology | Lead-acid |
| Length | 330 mm |
| Width | 173 mm |
| Height | 240 mm |
€494.50
VAT included
Tudor TB110B 12V 110Ah 950A is a ready-to-use passenger car battery, sealed and maintenance-free. Delivers the cranking amps the engine needs in cold weather and keeps stable voltage for modern car loads (ECU, sensors, climate control, infotainment).
Why this car battery?
- Original-equipment qualitywithout dealership prices
- Lasts 4 to 6 yearsbuy once instead of twice
- Real human tech supportif you have any doubts before buying
Voltage
12 V
Capacity
110 Ah
Cold cranking
950 A
Dimensions
330×173×240 mm
Technology
Lead-acid
Weight
27,4 kg
Model
TUDOR TECHNICA
Car battery Tudor TB110B Technica 110Ah 950A 12V
12VVoltage
110AhCapacity
950ACold cranking
27.40kgWeight
With 110 Ah at 12 V and 950 A of cold cranking current (EN), the Tudor TB110B from the Technica range is a starter battery built for passenger cars with conventional starting, without a Start-Stop system. It replaces the original battery without adaptation in cars with a 330 × 173 × 240 mm format: same 110 Ah capacity.
- Direct replacement for the original battery in size and terminals.
- Original-equipment build quality without the dealership price.
- Conventional lead-acid: the most proven and economical technology.
- Reliable cold starts, even after weeks without driving.
What the Tudor TB110B is for
The Tudor TB110B covers the needs of passenger cars with conventional starting, without a Start-Stop system: reliable starting, stable voltage for the electronics and a service life of several years in daily use. Check that it matches your current battery in size and terminal position. Check that it matches your current battery in dimensions, terminals and hold-down: this reference has a weight of 27.40 kg.
Will it fit your current battery tray?
In terms of format, the Tudor TB110B measures 330 × 173 × 240 mm (length × width × height) and weighs 27.40 kg. Checking the three dimensions and the terminal position before buying avoids the most common mistake when replacing a battery.
The Tudor TB110B: Technica range and conventional lead-acid technology
The Technica is the Tudor range the TB110B belongs to: it shares the same construction and quality criteria with the rest of the series, and varies in capacity and format to suit each vehicle.
Conventional lead-acid is the benchmark against which other technologies are compared: good cranking current, great tolerance to alternator charging and the best price per amp-hour.
What Tudor does differently
Tudor has made batteries in Spain for more than a century and remains one of the brands most trusted by Spanish workshops for reliability and value. All the Tudor batteries in our catalogue are genuine product, recently manufactured and covered by the manufacturer's warranty.
Manufacturer's warranty
The Tudor TB110B comes with the manufacturer's official warranty against manufacturing defects; the exact period is stated in the brand's conditions. If it fails through a defect within the period, we replace it free of charge.
Usage and maintenance tips
Avoid leaving lights or accessories on with the engine off: most batteries fail not through defects but through repeated deep discharges. Keep the terminals clean and tight, and check that the resting voltage does not drop below 12.4 V: below that it is time to recharge.
Shipping, delivery and returns
Order before 6:00 pm with stock available and it leaves today: mainland Spain and Portugal receive it in 24-48 working hours, the islands and the rest of the EU in 3 to 5 days. You have 14 days to return it if it has not been installed, with free collection on the mainland, and shipment tracking by email.
BCOM-TUDOR-TB110B
Data sheet
- Brand
- TUDOR
- Reference
- TB110B
- Model
- TUDOR TECHNICA
- Voltage (V)
- 12
- Length
- 330 mm
- Width
- 173 mm
- Height
- 240 mm
- Weight
- 27.40 Kgs
- Technology
- Lead-acid
- Terminal layout
- 9
- Cold cranking amps (EN)
- 950A
- Capacity (C20)
- 110Ah (c20)
Specific References
- MPN
- TB110B
Comparison: Tudor TB110B vs equivalents
The Tudor TB110B is interchangeable with these equivalent references: LFS105N (Varta), H17 (Varta), H16 (Varta).
| Product | Specifications | Technology | Price |
|---|---|---|---|
Tudor
TB110B
This battery
|
12V 110Ah 950A | Lead-acid | €494.50 |
Varta
LFS105N
|
12V 105Ah 800A | Lead-acid | €215.90 |
Varta
H17
|
12V 105Ah 800A | Lead-acid | €100.70 |
Varta
H16
|
12V 105Ah 800A | Lead-acid | €167.90 |
Equivalences verified by our technical team: same dimensions, polarity, capacity and CCA. Official manufacturer warranty on every option.
Recommended accessories
How to change the battery
Step-by-step guide to replace your car battery in 15-30 minutes (longer if the battery is under the seat or in the boot) without losing vehicle settings.
Step 1. Prepare the vehicle
Park on a flat surface, switch off the engine and remove the key. Make sure all lights and electrical accessories are off. Wait 1-2 minutes before starting.
Step 2. Locate the battery
Open the bonnet. The battery is usually in the engine bay, but in many modern cars it may be in the boot or under the passenger seat. Check the manual if you cannot find it.
Step 3. Disconnect the negative (−) terminal
Use the 10 mm wrench to loosen the negative cable nut (black, marked −) and remove the cable from the post. Move it aside so it cannot touch any bodywork.
Step 4. Disconnect the positive (+) terminal
Repeat with the positive cable (red, marked +). Important: never let a terminal touch metal of the car while the other is still connected.
Step 5. Remove the old battery
Loosen the bottom hold-down clamp with the same wrench. Lift the battery carefully (it can weigh 15-25 kg). Clean the tray with a brush and baking soda if there is corrosion.
Step 6. Install the new battery
Place the battery in the same orientation as the old one (positive terminal on the same side). Tighten the hold-down clamp firmly.
Step 7. Connect the cables
Connect the positive (+) terminal first, then the negative (−). Tighten the nuts with the wrench until each terminal does not move. Apply anti-spark grease if you have any.
Step 8. Verify the engine starts
Close the bonnet. Start the engine to confirm everything works. On cars with Start-Stop or a BMS, you may need to register the battery via OBD so the alternator applies the correct charging profile.
Frequently asked questions
How is the Tudor TB110B battery installed in the vehicle?
In most cars it fits in 15-30 minutes with a 10 mm wrench; if the battery is under the seat or in the boot the time can double. See the step-by-step guide on this page. Quick summary: 1) switch off the engine and remove the key; 2) locate the original battery (engine bay, boot or under seat); 3) disconnect the negative (−) terminal first, then the positive (+); 4) loosen the hold-down clamp and remove the old battery; 5) fit the new one in the same orientation — match the polarity shown on the product sheet; 6) connect the positive (+) first, then the negative (−). On cars with Start-Stop or BMS, register the battery via OBD so the alternator applies the correct charging profile.
How long does the Tudor TB110B battery last?
Expected lifespan of the Tudor TB110B is 4 to 6 years in regular car use without Start-Stop. In cold regions it drops slightly due to cold-start stress; in very hot regions it also drops because of electrolyte evaporation. To extend its life: avoid deep discharges (headlights on with engine off), have the alternator checked yearly, and keep the battery clean and properly secured.
What are the measurements of the TB110B model?
Dimensions (length × width × height) are 330×173×240 mm — also written as 330x173x240 mm — following the European DIN standard. Always measure the space in your car before buying: even one extra millimetre can prevent the hold-down clamp from closing. The height shown includes the terminals.
Does this battery fit my car?
Three options to confirm: 1) enter your number plate in the finder (DGT/DVLA/KBA auto-detect your model and engine); 2) check the "Compatible vehicles" tab on this page, where we list every vehicle verified by our technical team; 3) if you cannot find your model, message us on WhatsApp with brand, model, engine and year — we reply during business hours (Mon–Fri 10:00–13:30 and 16:40–18:00 (Spanish time, CET)). The TB110B typically fits a wide range of European vehicles thanks to its standard DIN case format.
Which batteries are equivalent to the Tudor TB110B?
Directly interchangeable batteries (same dimensions, same polarity, same Ah and CCA) are the OEM equivalents from leading brands: Bosch, Tudor, Exide and, depending on the model, Banner or Yuasa. Exact equivalence depends on technology — an EFB cannot be replaced with a conventional battery in Start-Stop cars. See the "Equivalents" section to view recommended options at the same performance level.
