Exide EA755 · Car battery 12V 75Ah 630A
Specifications
| Brand | EXIDE |
|---|---|
| Part number | EA755 |
| Voltage (V) | 12 |
| Capacity (C20) | 75Ah (c20) |
| Cold cranking amps (EN) | 630A |
| Technology | Lead-acid |
| Length | 270.00 cm |
| Width | 173.00 cm |
| Height | 222.00 cm |
€84.20
VAT included
Polarity: positive on the left. Check it matches your current battery before buying.
Exide EA755 12V 75Ah 630A is a starter battery with OEM-equivalent quality, designed for modern passenger cars. Delivers reliable cold-cranks even after weeks of inactivity and supports stable auxiliary loads (lights, climate control, infotainment).
Why this car battery?
- Original-equipment qualitywithout dealership prices
- Lasts 4 to 6 yearsbuy once instead of twice
- Real human tech supportif you have any doubts before buying
Voltage
12 V
Capacity
75 Ah
Cold cranking
630 A
Dimensions
270×173×222 mm
Technology
Lead-acid
Polarity
Positive on the left
Weight
17,4 kg
Model
EXIDE Premium
Car battery Exide EA755 Premium 75Ah 630A 12V
12VVoltage
75AhCapacity
630ACold cranking
18.60kgWeight
The Exide EA755 from the Premium range delivers 75 Ah and 630 A of cold cranking current (EN) at 12 V: the usual specification for passenger cars with conventional starting, without a Start-Stop system. Its 270 × 173 × 222 mm and the positive terminal on the left make it the exact replacement for the 75 Ah battery fitted as standard to many cars.
- Designed to last several years under normal daily use.
- Low self-discharge: copes with long stops without losing charge.
- Stable voltage for the vehicle electronics (ECU, sensors, climate control).
- Good balance of capacity, cranking power and price.
Size, terminals and hold-down of the Exide EA755
In terms of format, the Exide EA755 measures 270 × 173 × 222 mm (length × width × height) and weighs 18.60 kg. The positive terminal on the left decides which side the cables end up on: it is the detail that causes most buying mistakes, so check it before ordering. It uses a Korean B1+B6 hold-down and 1 terminals, the system that anchors and connects it in the vehicle. For a direct replacement, the current battery tray must accept these dimensions and the same terminal layout; otherwise adapters will be needed or the hold-down will change.
What the Exide EA755 is for
With 75 Ah, the Exide EA755 is sized for passenger cars with conventional starting, without a Start-Stop system. It is a direct replacement for the original battery as long as dimensions and terminals match. Check that it matches your current battery in dimensions, terminals and hold-down: this reference has a weight of 18.60 kg, 1 terminals and Korean B1+B6 hold-down.
The Exide EA755: Premium range and conventional lead-acid technology
Within the Exide catalogue, the Premium series groups the references designed for this use. The EA755 is the 75 Ah model of that family, with the same performance as its siblings in other sizes.
The conventional lead-acid battery remains the most widespread technology thanks to its balance of capacity, cranking current and price. Well maintained and kept charged, it offers years of reliable service in vehicles without Start-Stop.
What Exide does differently
With more than a century of history, Exide Technologies manufactures automotive, marine, motorcycle and industrial batteries in Europe. Its presence as original equipment on assembly lines vouches for the quality of every reference. All the Exide batteries in our catalogue are genuine product, recently manufactured and covered by the manufacturer's warranty.
Manufacturer's warranty
The Exide EA755 comes with the manufacturer's official warranty against manufacturing defects; the exact period is stated in the brand's conditions. If it fails through a defect within the period, we replace it free of charge.
How to make it last longer
Avoid leaving lights or accessories on with the engine off: most batteries fail not through defects but through repeated deep discharges. In normal daily use the alternator keeps the battery charged; if the car stands for weeks, a maintenance charge once a month prevents deep discharge.
Shipping, delivery and returns
Order before 6:00 pm with stock available and it leaves today: mainland Spain and Portugal receive it in 24-48 working hours, the islands and the rest of the EU in 3 to 5 days. You have 14 days to return it if it has not been installed, with free collection on the mainland, and shipment tracking by email.
BCOM-EXIDE-EA755
Data sheet
- Brand
- EXIDE
- Reference
- EA755
- Model
- EXIDE PREMIUM
- Voltage (V)
- 12
- Length
- 270.00 cm
- Width
- 173.00 cm
- Height
- 222.00 cm
- Weight
- 18.60 Kgs
- Technology
- Lead-acid
- EAN
- 3661024034173
- Terminal layout
- Positive terminal on the left
- Terminal type
- 1
- Hold-down
- Korean B1+B6
- Cold cranking amps (EN)
- 630A
- Capacity (C20)
- 75Ah (c20)
- Case type
- D26
Specific References
- EAN13
- 3661024034173
- MPN
- EA755
Codes and references Exide EA755
| Brand | Exide · see all Exide batteries |
|---|---|
| Manufacturer range | EXIDE PREMIUM |
| Manufacturer part number (MPN) | EA755 |
| EAN-13 barcode | 3661024034173 |
| Dimensions (length × width × height) | 270 × 173 × 222 mm (270x173x222) |
Comparison: Exide EA755 vs equivalents
The Exide EA755 is interchangeable with these equivalent references: TA755 (Tudor), TB705 (Tudor), EB705 (Exide), EC605 (Exide), TC605 (Tudor).
| Product | Specifications | Technology | Price |
|---|---|---|---|
Exide
EA755
This battery
|
12V 75Ah 630A | Lead-acid | €84.20 |
Tudor
TA755
|
12V 75Ah 630A | Lead-acid | €98.80 |
Tudor
TB705
|
12V 70Ah 540A | Lead-acid | €68.40 |
Exide
EB705
|
12V 70Ah 540A | Lead-acid | €73.70 |
Exide
EC605
|
12V 60Ah 440A | Lead-acid | €99.40 |
Tudor
TC605
|
12V 60Ah 440A | Lead-acid | €77.70 |
Equivalences verified by our technical team: same dimensions, polarity, capacity and CCA. Official manufacturer warranty on every option.
Recommended accessories
How to change the battery
Step-by-step guide to replace your car battery in 15-30 minutes (longer if the battery is under the seat or in the boot) without losing vehicle settings.
Step 1. Prepare the vehicle
Park on a flat surface, switch off the engine and remove the key. Make sure all lights and electrical accessories are off. Wait 1-2 minutes before starting.
Step 2. Locate the battery
Open the bonnet. The battery is usually in the engine bay, but in many modern cars it may be in the boot or under the passenger seat. Check the manual if you cannot find it.
Step 3. Disconnect the negative (−) terminal
Use the 10 mm wrench to loosen the negative cable nut (black, marked −) and remove the cable from the post. Move it aside so it cannot touch any bodywork.
Step 4. Disconnect the positive (+) terminal
Repeat with the positive cable (red, marked +). Important: never let a terminal touch metal of the car while the other is still connected.
Step 5. Remove the old battery
Loosen the bottom hold-down clamp with the same wrench. Lift the battery carefully (it can weigh 15-25 kg). Clean the tray with a brush and baking soda if there is corrosion.
Step 6. Install the new battery
Place the battery in the same orientation as the old one (positive terminal on the same side). Tighten the hold-down clamp firmly.
Step 7. Connect the cables
Connect the positive (+) terminal first, then the negative (−). Tighten the nuts with the wrench until each terminal does not move. Apply anti-spark grease if you have any.
Step 8. Verify the engine starts
Close the bonnet. Start the engine to confirm everything works. On cars with Start-Stop or a BMS, you may need to register the battery via OBD so the alternator applies the correct charging profile.
Frequently asked questions
How do I fit the EA755 model in my car?
In most cars it fits in 15-30 minutes with a 10 mm wrench; if the battery is under the seat or in the boot the time can double. See the step-by-step guide on this page. Quick summary: 1) switch off the engine and remove the key; 2) locate the original battery (engine bay, boot or under seat); 3) disconnect the negative (−) terminal first, then the positive (+); 4) loosen the hold-down clamp and remove the old battery; 5) fit the new one in the same orientation — match the polarity shown on the product sheet; 6) connect the positive (+) first, then the negative (−). On cars with Start-Stop or BMS, register the battery via OBD so the alternator applies the correct charging profile.
How long does the Exide EA755 battery last?
Expected lifespan of the Exide EA755 is 4 to 6 years in regular car use without Start-Stop. In cold regions it drops slightly due to cold-start stress; in very hot regions it also drops because of electrolyte evaporation. To extend its life: avoid deep discharges (headlights on with engine off), have the alternator checked yearly, and keep the battery clean and properly secured.
What are the measurements of the EA755 model?
Dimensions (length × width × height) are 270×173×222 mm — also written as 270x173x222 mm — following the European DIN standard. Always measure the space in your car before buying: even one extra millimetre can prevent the hold-down clamp from closing. The height shown includes the terminals.
Is the EA755 valid for my vehicle?
Three options to confirm: 1) enter your number plate in the finder (DGT/DVLA/KBA auto-detect your model and engine); 2) check the "Compatible vehicles" tab on this page, where we list every vehicle verified by our technical team; 3) if you cannot find your model, message us on WhatsApp with brand, model, engine and year — we reply during business hours (Mon–Fri 10:00–13:30 and 16:40–18:00 (Spanish time, CET)). The EA755 typically fits a wide range of European vehicles thanks to its standard DIN case format.
What are the equivalents of the EA755 model?
Directly interchangeable batteries (same dimensions, same polarity, same Ah and CCA) are the OEM equivalents from leading brands: Bosch, Tudor, Exide and, depending on the model, Banner or Yuasa. Exact equivalence depends on technology — an EFB cannot be replaced with a conventional battery in Start-Stop cars. See the "Equivalents" section to view recommended options at the same performance level.
