Exide EK1050 · Start-Stop battery 105Ah 950A AGM

Yes, it is AGM. In an AGM battery such as the EK1060, the electrolyte is not free but absorbed in a glass-fibre mat inside a sealed lead-acid battery. It is the technology required by cars with advanced Start-Stop and regenerative braking. It withstands more cycles than a conventional battery and copes better with heat.

Yes. It is a AGM battery of 106 Ah, designed for vehicles with Start-Stop. AGM batteries support advanced Start-Stop and regenerative braking thanks to their higher cycle count. Registering it via OBD is advisable on most modern cars (the alternator then applies the optimum profile), but it works from the start. The general recommendation is EFB for basic Start-Stop and AGM where there is regenerative braking (it handles more cycles), unless the car manufacturer says otherwise.

Before you start, check the car handbook: the manufacturer's procedure always comes first. Our full step-by-step guide is on the blog. On most cars it is a 15-30 minute job needing only a 10 mm spanner (up to twice as long when the battery is under a seat or in the boot). The right order: engine off and key out; disconnect the negative (−) first, then the positive (+); release the hold-down clamp, lift out the old battery and seat the new one in the same position (positive on the right), keeping the polarity; reconnect the positive (+) first and the negative (−) last. If the car has Start-Stop or BMS: a) the technology must match the original (AGM or EFB) or be higher, because a conventional battery would fail within months; b) undo the negative cable at its nut, leaving the IBS sensor in place; c) it is advisable to register the battery via OBD so the alternator applies the proper charging profile.

Estimated lifespan of the Exide EK1060: 5 to 8 years in mild-climate car use with Start-Stop. Treat it as an approximate guide, as every case is different. It can vary considerably with usage (short or long journeys), temperature, the condition of the alternator and charging system, power drawn with the engine off and maintenance, plus the car itself and Start-Stop. Cold demands more at every start and intense heat evaporates the electrolyte.

Measure your car's battery tray first; if the battery exceeds it by even a millimetre, the hold-down clamp may not close. Length × width × height: 392x175x190 mm (L6 case). Height is measured to the top of the terminals. Hold-down: B13.

The EK1060 has the positive on the right in a L6 case: that is its polarity. If your current battery has its positive on the other side, this one is not suitable without longer cables or a reconfigured system (short-circuit risk). Face the battery with its terminals nearest you and see which side the positive post (+, red ring) is on.

Not sure? Try your number plate in the finder (DGT/DVLA/KBA detect model and engine) or the "Compatible vehicles" tab, checked by our technical team; if your car is not there, send us make, model, engine and year on WhatsApp and we will reply during business hours (Mon–Fri 10:00–13:30 and 16:30–18:00 (Spanish time, CET)). If our table and the car handbook disagree, go with what the manufacturer says.

To replace the Exide EK1060 without modifications, the other battery must be identical in size (L6 case), polarity, Ah and CCA. See the "Equivalents" section of this page for the recommended options at the same performance level. Mind the technology: in Start-Stop cars an EFB is not swapped for a conventional battery.

Same case and same fitting as the EK1050, from Varta. Compared with the EK1050 it has 1 Ah less. It costs 73,60 € more. If you want to save or the EK1050 is out of stock, it is the safe alternative: same dimensions, same polarity and official warranty.

This EK1060 delivers 950 A cold cranking (EN). Many more charge/discharge cycles than a conventional battery and no leaks: that is what AGM technology brings, with the electrolyte absorbed in glass fibre. For regenerative braking systems such as BMW EfficientDynamics, Mercedes Eco, Audi MHEV, Land Rover ECO or Volvo i-Stop, AGM is the recommendation; it also copes better than an EFB with tilting, vibration and extreme temperatures.

The alternator detects the new battery and adapts the charge automatically, so on most cars it is not compulsory. Even so, it is advisable to register it via OBD so charging is optimum from the first minute and the battery lasts longer, particularly on BMW, Mercedes, Audi, Volvo or Land Rover, with more sophisticated BMS. Without registration the car starts normally; the alternator simply takes a few days to adjust the profile. Any workshop with an OBD scanner does it in a few minutes; DIY, with VCDS or Carista (VAG group), Bimmercode (BMW) or iCarsoft.
