Motobatt MBTX30U · Motorcycle battery 12V 32Ah 385A AGM
Specifications
| Brand | MOTOBATT |
|---|---|
| Part number | MBTX30U |
| Voltage (V) | 12 |
| Capacity (C20) | 32Ah (c20) |
| Capacity (C10) | 32Ah (c10) |
| Technology | Quadflex |
| Length | 166.00 mm |
| Width | 126.00 mm |
| Height | 175.00 mm |
€174.50
VAT included
4,82/5★★★★★20 reviewsVerified purchases
- ★★★★Manuel Gil:
baterias.com, los mejores
- ★★★★★Luis Miguel Campos:
Gracias a vuestra ayuda pude instalar la batería
- ★★★★Salvador Castro:
Tenía dudas pero cuando hablé con ellos, me convencieron. La recomiendo
Motobatt MBTX30U 12V 32Ah 385A is a motorcycle starter battery with standard JIS code (the one on your bike's original label). Ready to use, sealed and vibration-resistant. Fits any model that takes the same JIS reference — the code your mechanic recognises at a glance.
Why this motorcycle battery?
- Same JIS referenceas your bike's original — fits first time
- Sealed and ready to useno acid handling, no refills
- Survives winter storageholds charge through long off-season
JIS code
Y60N24LA, Y60N24ALB, YIX30L, YB30LB, YB30CLB, Y60N30LA, 53030
Voltage
12 V
Capacity
32 Ah
Cold cranking
385 A
Dimensions
166×126×175 mm
Technology
AGM Quadflex
Weight
10,2 kg
Model
MOTOBATT QUADFLEX
Mfr. reference
MBTX30U
Motorcycle battery Motobatt Y60N24LA Quadflex 32Ah 385A 12V
Equivalent JIS codesY60N24LAY60N24ALBYIX30LYB30LBYB30CLBY60N30LA-53030
12VVoltage
32AhCapacity
385ACold cranking
10.20kgWeight
The Motobatt Y60N24LA from the Quadflex range is a motorcycle battery with 32 Ah and 385 A of cold cranking current (EN), designed for motorcycles, scooters, quads and personal watercraft. It measures 166 × 126 × 175 mm, the format sought by anyone replacing a 32 Ah battery in motorcycles.
- Energetic cranking for high-compression engines.
- Resistant to the vibration typical of two wheels.
- Same JIS code as the original battery: fits first time.
- AGM technology: absorbed electrolyte, no spills, can be mounted at an angle.
What the Motobatt Y60N24LA is for
With 32 Ah, the Motobatt Y60N24LA covers the starting of motorcycles, scooters, quads and personal watercraft. The JIS code on your current battery label is the safest way to confirm equivalence. Check that it matches your current battery in dimensions, terminals and hold-down: this reference has a weight of 10.20 kg.
Size, terminals and hold-down of the Motobatt Y60N24LA
It has external dimensions of 166 × 126 × 175 mm and weighs 10.20 kg. Checking the three dimensions and the terminal position before buying avoids the most common mistake when replacing a battery.
The Motobatt Y60N24LA: Quadflex range and AGM technology
Within the Motobatt catalogue, the Quadflex series groups the references designed for this use. The Y60N24LA is the 32 Ah model of that family, with the same performance as its siblings in other sizes.
AGM (Absorbent Glass Mat) technology seals the electrolyte in glass microfibre. The result is a maintenance-free battery that is highly vibration-resistant and able to withstand deep discharges that would ruin a classic lead-acid battery.
Motobatt: the maker behind the Y60N24LA
Motobatt is the motorcycle battery specialist with Quadflex technology: four terminals that let you connect the battery in any position and a sealed AGM construction ready to fit. At baterias.com we work directly with the manufacturer or its official distributor: real stock, brand-new product and official warranty.
Official warranty
The Motobatt Y60N24LA comes with the manufacturer's official warranty. The warranty does not cover discharge through prolonged inactivity: if the bike stands for months, use a trickle charger.
How to make it last longer
Charge with a charger that has an AGM mode: it limits the voltage and protects the glass-fibre separators. Check the resting voltage before the season (above 12.6 V on a charged battery) and make sure the terminals are clean and tight.
Shipping, delivery and returns
Order before 6:00 pm with stock available and it leaves today: mainland Spain and Portugal receive it in 24-48 working hours, the islands and the rest of the EU in 3 to 5 days. You have 14 days to return it if it has not been installed, with free collection on the mainland, and shipment tracking by email.
BCOM-MOTOBATT-MBTX30U
Data sheet
- Brand
- MOTOBATT
- Reference
- MBTX30U
- Model
- MOTOBATT QUADFLEX
- Voltage (V)
- 12
- Length
- 166.00 mm
- Width
- 126.00 mm
- Height
- 175.00 mm
- Weight
- 10.2 Kgs
- Technology
- Quadflex
- JIS
- Y60N24LA Y60N24ALB YIX30L YB30LB YB30CLB Y60N30LA-53030
- Cold cranking amps (EN)
- 385A
- Capacity (C20)
- 32Ah (c20)
- Capacity (C10)
- 32Ah (c10)
Specific References
- MPN
- MBTX30U
4,82/5
Verified purchasesLatest verified reviews
★★★★★Manuel Gil
14/07/2026Buena elección para mi batería
baterias.com, los mejores
★★★★★Luis Miguel Campos
22/05/2026Me ayudaron a elegir la batería correcta
Gracias a vuestra ayuda pude instalar la batería
★★★★★Salvador Castro
04/04/2026Muy recomendable
Tenía dudas pero cuando hablé con ellos, me convencieron. La recomiendo
★★★★★Ramon Ramos
05/02/2026Buen sitio
No tenía ni idea de cómo instalar la batería en mi coche y me ayudaron de principio a fin. Muchas gracias
★★★★★Cesar Gonzalez
03/01/2026Gracias
No sabía que batería necesitaba mi vehículo y ellos me indicaron la mejor opción. Muy amables
★★★★★Roberto Calvo
02/01/2026Ayudan con la instalación
Al final fue facil la instalación gracias a su ayuda
★★★★★Juan Carlos Cortes
30/12/2025Muy recomendable
Para mi gusto esta web lo tiene todo, variedad de productos, atención telefónica buena, entrega en plazo y asesoría gratis al momento de la instalación.
★★★★★Juan Carlos Castillo
12/11/2025Buen asesoramiento
Para los que no entendemos de baterias se agradece su ayuda
Comparison: Motobatt MBTX30U vs equivalents
The Motobatt MBTX30U is interchangeable with these equivalent references: MBTX30UHD (Motobatt).
| Product | Specifications | Technology | Price |
|---|---|---|---|
Motobatt
MBTX30U
This battery
|
12V 32Ah 385A | Quadflex | €174.50 |
Motobatt
MBTX30UHD
|
12V 32Ah 385A | Quadflex | €266.50 |
Equivalences verified by our technical team: same dimensions, polarity, capacity and CCA. Official manufacturer warranty on every option.
Recommended accessories
How to change the battery
Guide to replace your motorcycle battery in 10-15 minutes. Motorcycle batteries are light (2-5 kg) and usually need an 8 mm wrench.
Step 1. Prepare the vehicle
Park on a flat surface, switch off the engine and remove the key. Make sure all lights and electrical accessories are off. Wait 1-2 minutes before starting.
Step 2. Locate the battery compartment
On motorcycles it is usually under the seat, in the rear cowl or behind a side panel. Check the manual — access varies a lot between models.
Step 3. Disconnect the negative (−) terminal
Use the 10 mm wrench to loosen the negative cable nut (black, marked −) and remove the cable from the post. Move it aside so it cannot touch any bodywork.
Step 4. Disconnect the positive (+) terminal
Repeat with the positive cable (red, marked +). Important: never let a terminal touch metal of the car while the other is still connected.
Step 5. Remove the old battery
Loosen the hold-down clamp or the straps that secure it. Lift the battery carefully — typical weight 2-5 kg. Check the terminals are not corroded before fitting the new one.
Step 6. Install the new battery
Place the battery in the same orientation as the old one (positive terminal on the same side). Tighten the hold-down clamp firmly.
Step 7. Connect the cables
Connect the positive (+) terminal first, then the negative (−). Tighten the nuts with the wrench until each terminal does not move. Apply anti-spark grease if you have any.
Step 8. Verify the engine starts
Close the bonnet. Start the engine to confirm everything works. On cars with Start-Stop or a BMS, you may need to register the battery via OBD so the alternator applies the correct charging profile.
Frequently asked questions
How do I fit the Y60N30LA-53030 model in my motorcycle?
In most motorcycles it fits in 15-30 minutes with a 10 mm wrench; if the battery is under the seat or in the boot the time can double. See the step-by-step guide on this page. Quick summary: 1) switch off the engine and remove the key; 2) locate the original battery (engine bay, boot or under seat); 3) disconnect the negative (−) terminal first, then the positive (+); 4) loosen the hold-down clamp and remove the old battery; 5) fit the new one in the same orientation — match the polarity shown on the product sheet; 6) connect the positive (+) first, then the negative (−). On motorcycles with Start-Stop or BMS, register the battery via OBD so the alternator applies the correct charging profile.
What is the service life of the Y60N30LA-53030 model?
Expected lifespan of the Motobatt Y60N30LA-53030 is 4 to 7 years in regular use (depends on technology and climate). In cold regions it drops slightly due to cold-start stress; in very hot regions it also drops because of electrolyte evaporation. To extend its life: avoid deep discharges (headlights on with engine off), have the alternator checked yearly, and keep the battery clean and properly secured.
What are the measurements of the Y60N30LA-53030 model?
Dimensions (length × width × height) are 166×126×175 mm — also written as 166x126x175 mm — following the European DIN standard. Always measure the space in your motorcycle before buying: even one extra millimetre can prevent the hold-down clamp from closing. The height shown includes the terminals.
Is the Y60N30LA-53030 valid for my vehicle?
Three options to confirm: 1) enter your number plate in the finder (DGT/DVLA/KBA auto-detect your model and engine); 2) check the "Compatible vehicles" tab on this page, where we list every vehicle verified by our technical team; 3) if you cannot find your model, message us on WhatsApp with brand, model, engine and year — we reply during business hours (Mon–Fri 10:00–13:30 and 16:40–18:00 (Spanish time, CET)). The Y60N30LA-53030 typically fits a wide range of European vehicles thanks to its standard DIN case format.
Which batteries are equivalent to the Motobatt Y60N30LA-53030?
Directly interchangeable batteries (same dimensions, same polarity, same Ah and CCA) are the OEM equivalents from leading brands: Bosch, Tudor, Exide and, depending on the model, Banner or Yuasa. Exact equivalence depends on technology — an EFB cannot be replaced with a conventional battery in Start-Stop motorcycles. See the "Equivalents" section to view recommended options at the same performance level.
